Miter Saw 650 (Double Column Semi-Automatic Band saw)

The Vijay Machinery Miter Saw 650 is a double-column semi-automatic bandsaw with a 650 mm cutting capacity, designed for accurate angled cuts on large metal materials.

Its double-column structure ensures stability and reduces vibrations, while the semi-automatic operation automates clamping and cutting. This model allows for manual angle adjustments, making it ideal for industrial applications requiring precision and flexibility in miter cutting tasks.

Category:
Description

Technical Specification

Category Specification
Model MiterSaw650
Type Semi-Automatic Double Column, Semi-Automatic Miter Cutting Band Saw Machine
Cutting Capacity
– Round 650mm
– Square 650mm(H) x 800mm(W)
– 45 Degree 600mm(H) x 600mm(W)
– 60 Degree 600mm(H) x 500mm(W)
Blade Specifications
– Blade Size 9000x54x1.3mm
– Blade Speed 15 to 80 m/min
Motors
– Saw Motor 7.5HP, 5.5kW
– Hydraulic Motor 2HP, 1.25kW
– Coolant Pump 0.18HP
Machine Size (L)4700mm x (W)2060mm x (H_min)2650 x (H_max)2900mm
Machine Weight 4500 kg Approx.
Cutting Accuracy
– Taper Cutting Accuracy 0 to 100 mm OD = (± 0.2 to ±0.5 mm, depending on the surface of the material)
– Degree Accuracy (± 0.5° to ±1.0°, depending on the surface of the material)
Advanced Features
– Chip brush Effective chip removal from blade
– Blade Tension Manual
– Working Light Included
– Warm Gear Box Included
– Manual Adjust Blade Guide ARM
Standard Accessories
– Operation Tools Spanner Set
– Bi Metal Band Saw Blade Included
Components and Brand
– Saw Motor LHP (Laxmi Hydraulic PVT LTD)
– Coolant Pump Rajamani
– Electric Components Schneider and Siemens
– Sensor and Limit Switch Autonics, Taiwan
– Flow Control Valve Rexroth
– Hydraulic Direction Valve Yuken
– All Bearing SKF & FAG & NTN Japan
