Description
Technical Specification
| Model | Atal4370S (EION-VX4) | |
| Cutting Capacity | – Round: 430 mm – Square: 430 mm (H) x 700 mm (W) |
|
| Blade Specifications | – Size: 5900 x 41 x 1.3 mm – Speed: 15–80 (With Inverter VFD) |
|
| Motors | – Saw Motor: 7.5 HP / 5.5 kW – Hydraulic Motor: 1.0 HP / 0.75 kW |
|
| Tanks | – Hydraulic Oil Tank: 40 L – Coolant Tank: 60 L |
|
| Coolant Pump | 0.18 HP | |
| Machine Dimensions | 3300 x 2700 x 1920 mm (W x L x H) | |
| Machine Weight | 2400 kg | |
| Cutting Accuracy | Taper Cutting Accuracy: 0 to 100 mm OD = (± 0.2 to ± 0.5 mm, depends on material surface) | |
| Advanced Features | – Saw frame height selector gauge – Helical Gear Drive – Origin System (returns to home position after cutting) – Auto Change Blade Speed – Hydraulic blade tension – Working light |
|
| Standard Accessories | – Operation Tools & Spanner Set – Bi Metal Band Saw Blade – Vibration Pad |
|
| Components and Brands | – Saw Motor: Lakshmi, UHP – Coolant Pump: Rajamani – Low Voltage Electric Components: Schneider – Flow Control Valve: Rexroth – Hydraulic Direction Valve: Yuken |
|
